| Picture Quality | Display | Panel |
4K ULTRA HD / HDR Cinema Display Pro |
|---|
| Screen Resolution |
3,840 (W) x 2,160 (H) |
|---|
| Panel Drive |
4K 2200 Hz BMR IFC |
|---|
| Picture Mode |
Dynamic/Normal/Cinema/True Cinema/Custom/Sport/Game/DolbyVision (Vivid/Bright/Dark) |
|---|
| Ultra HD Premium*1 |
— |
|---|
| Multi HDR Support*2 |
HDR10+/HDR10/HLG/DolbyVision/HLG Photo*16 |
|---|
| Dolby Vision IQ |
— |
|---|
| Filmmaker Mode |
— |
|---|
| HDR Brightness Enhancer |
Y |
|---|
| Dynamic HDR Effect |
Y |
|---|
| Contrast |
Supreme Contrast |
|---|
| Colour Space |
Wide Colour Spectrum |
|---|
| Advanced Video Processor/Engine |
HCX Pro Intelligent Processor |
|---|
| Local Dimming |
Local Dimming Pro Intelligent |
|---|
| Adaptive Backlight Dimming |
— |
|---|
| isf Mode |
— |
|---|
| Sound Quality | Dolby Atmos |
Y |
|---|
| Surround |
Cinema Surround |
|---|
| Speaker Output |
20 W (10 W x 2) |
|---|
| Sound Mode |
Standard/Music/Speech/Stadium/User |
|---|
| Smart Features | Smart TV |
my Home Screen5.0 |
|---|
| Works with Google Assistant*3 |
Y |
|---|
| Works with Alexa*4 |
Y |
|---|
| Voice Guidance |
Y |
|---|
| EPG |
Y |
|---|
| On Screen Display Menu Languages |
27 Languages*17 |
|---|
| Digital TV |
DVB-T/T2/DVB-S2/DVB-C |
|---|
| Twin Tuner |
Y |
|---|
| Wireless LAN Built-in |
Y |
|---|
| TV Anywhere*5 |
Y |
|---|
| In-House TV Streaming (DVB-IP) |
Y (Server / Client) |
|---|
| Panasonic TV Remote Apps | Panasonic TV Remote Apps |
Y |
|---|
| Swipe & Share |
Y |
|---|
| Web Browser*6 |
Y |
|---|
| Mirroring |
Y (Easy Mirroring) |
|---|
| Home Network*7 |
Y (Server / Client) |
|---|
| Bluetooth*8 |
Y
HID / HOGP (Keyboard/Mouse)
A2DP (Audio In/Out) |
|---|
| Bluetooth Audio Link*9 |
Y |
|---|
| IP Home Control |
Y |
|---|
| Media Player | Media Player |
Y (2.0)*18 |
|---|
| Support Format |
AVI/HEVC/MKV/WMV/MP4/M4v/FLV/3GPP/VRO/VOB/TS/PS, MP3/AAC/WMA Pro/FLAC/Apple Lossless/WAV, JPEG/HLG Photo |
|---|
| Data Broadcasting |
Hbb TV |
|---|
| Teletext Reception |
1500P |
|---|
| USB-HDD Recording*10 |
Y (w/ Rewind live TV) |
|---|
| Multi Window |
2T PAP/PIP/PAT |
|---|
| HDAVI Control |
Y |
|---|
| Netflix Recommended TV |
Y |
|---|
| Energy Data | Suppliers Trademark |
Panasonic |
|---|
| Model ID |
TX-75HX940E |
|---|
| Energy Efficiency Class |
A+ |
|---|
| Visible Screen Size (diagonal) |
189 cm / 75 inches |
|---|
| On mode Average Power Consumption*11 |
129W |
|---|
| Annual Energy Consumption*12 |
179kWh/Y |
|---|
| Standby Power Consumption |
0.5W |
|---|
| Off mode Power Consumption |
0.3W |
|---|
| Screen Resolution |
3,840 (W) x 2,160 (H) |
|---|
| Power Supply |
AC 220 - 240 V, 50/60 Hz |
|---|
| Rated Power Consumption |
255W |
|---|
| Ambient Sensor (CATS) |
Y |
|---|
| Design | Swivel Design |
— |
|---|
| Switch Design |
— |
|---|
| Terminal | Digital Tuner Reception |
DVB-T/T2/DVB-S2/DVB-C |
|---|
| Analogue Tuner |
Y |
|---|
| HDMI*13 | HDMI |
2 (side), 2 (rear) |
|---|
| HDMI (4K 60/50p with HDCP2.2) |
4 |
|---|
| Support Feature |
Audio Return Channel (Input 2)
HDMI2.1 Auto low Latency mode |
|---|
| USB |
3 (1 side, 2 rear; USB 3.0 x 1, USB 2.0 x 2) |
|---|
| Ethernet |
1 |
|---|
| CI (Common Interface) |
2 (CI Plus, Version 1.4, ECP) |
|---|
| Scart Connector |
— |
|---|
| Analogue Video Input |
RCA phono type x 1 (rear) |
|---|
| Component Video Input shared with Composite |
RCA phono type x 1 (rear) |
|---|
| Digital Audio Output (Optical) |
1 (rear) |
|---|
| Digital Audio Output (Coax) |
— |
|---|
| PC input (VGA) + PC Audio In |
— |
|---|
| Headphone Output |
1 (side; switchable to Subwoofer) |
|---|
| GENERAL | Included Accessory*14 |
TV Remote |
|---|
| Dimensions (W x H x D) (w/o stand) |
1,680 x 966 x 70 mm |
|---|
| Dimensions (W x H x D) (with stand)*15 |
1,680 x 1,033 x 350 mm |
|---|
| Weight (w/o stand) |
53.0kg |
|---|
| Weight (with stand) |
60.0kg |
|---|
| Dimension Pedestal (W x D) |
500 x 350 mm |
|---|
| VESA Compatible |
Y |
|---|
| VESA Dimension (W x H) |
600 x 300 mm |
|---|
| Outer Boxed Unit (W x H x D) |
2,091 x 1,076 x 277 mm |
|---|
| Total Boxed Weight |
73kg |
|---|
